ECMA-23 is a standard for a bit-paired keyboard layout adopted in 1969 and revised in 1975. As a bit-paired layout, shifted keys correspond to toggling bits in the ASCII keycode. This is most visible in the digits on the top row, where shifting 6789 give &'(), and ; , :* and -= are paired.
The ECMA-23 layout has two options, being the same as the ISO 2530 or the ANSI-X4.14 bit-paired layout.
In the UK, ECMA-23 layout keyboards were used on most 8-bit computers such as the Acorn BBC computers and the earlier Atom and Systems, the Amstrad CPC series, and (to an extent) the ZX Spectrum. While bit-paired layouts have generally given way to typewriter layouts, the Japanese keyboard layout still uses one.
Technical details
- The _ and \| keys may be at the left as per ISO2530 or at the right as per ANSI-X4.14.
- Character 96 is generated either with Shift-_ with @ a singleton key, or with Shift-@ with _ a singleton key.
- Underline may be generated with Shifted-0 instead of with its own key. If this is done then Shift-@ is used to generate character 96.
- If a key is labelled ← Backspace it should be at the top-right; if a key is labelled DELETE it should be at the bottom-right.
- If the key to the left of 1 is not _, it is ESCAPE.
The most common layouts are:
- "BBC Micro": ECMA23/ANSI with Shift-_ generating character 96
- "Japan": ECMA23/ANSI with Shift-@ generating character 96 and an extra key to the right of /? generating \_
- "PC": ECMA23/ISO with Shift-_ generating character 96
